VELMEX VXM-3 - Page 74

Feature
AddressableAxes/Control
MotorCompatibility
MotoroutputtorqueaspercentofNF90
(M091Motor)
Steps/revolution
SpeedRange(steps/sec)
ProgramStorage (memorytype)
Rangeforuser
UserInputs
UserOutputs
OtherInputs
OtherOutputs
UserInterfaces
RS-232Configuration
DefaultBaudRate
MaximumBaudRate
“PulseEveryx#Steps”
VXM
1,2,3*,4*
*
By2ndVXMlinkedwithVXMbus
Size17tosize34(0.4to4.7amp)
400
1to6000
5 (RAM/FLASH)
0to32,767
185%@0.2rev/sec
200%@5rev/sec
340%@10rev/sec
Run (ActiveLow)
In1** (ActiveLow)In
2** (Multifunction)In
3** (Multifunction)In
4** (StopInterrupt)In
A**
 (Analog)
Out1**
Out2**
OptionalOut3**
OptionalOut4**
+5VDC**
**x2forLinkedVXMs
AC/DCPower
LimitSwitch(OpticallyIsolated)
Motor(6wireUnipolar)
RS-232(Tx,Rx,Gnd)
Run,Stop,andJogKeys
Opt.SpeedPot.
AnalogJoystick
RemoteJog
Opt.ProgramSel.Switch
8Data,NoParity,1Stop
9600
38,400
7
