x
Requestcapturedmotor1 positionsfromFIFObuffer(all4positions.)
NOTE: bufferdataisautomaticallyzeroedatthestartofeveryrun.
+0000521
+0000919
+0001149
+0000000
Example:
ThisexampleshowsthevaluestheVXMreturnedwhenthe“!”wassentat
positions521,919,and1149whilemotor1wasindexing.
y
Requestcapturedmotor2 positionsfromFIFObuffer(all4positions.)
NOTE: bufferdataisautomaticallyzeroedatthestartofeveryrun.
-0002004
+0000000
+0000000
+0000000
Example:
ThisexampleshowsthevaluestheVXMreturnedwhenthe“!”wassentat
positionnegative2004whilemotor2wasindexing.
SeeAlso
X, Y,
setIx
