VeloFox DM05 User Manual

Wheel
size
setting
dIA=Wheel
diameter
Value=12，14，
16，20，24，26，
27，27.5，
700C，28，*29，
*CCF
（*
default unit
is inch）
Default
value：
26
When
value=CCF,
customization
is allowed
Speed
limitation
setting
SPd=Speed
limitation
Value=5-46,
increment is 1，
unit is km/h 。
Default
value：25
Software
version
info
DPS= Display
software
version
Read only Default value
* Note: The wheel diameter option CCF is the wheel diameter perimeter setting, which needs to
be supported by communication protocol of motor controller.
When the CCF value is selected for the wheel diameter parameter, user is allowed to customize
the wheel diameter circumference value (four-digit length value in mm).
Long press M for selecting CCF, when speed display area shows blinking icon and function
display area shows wi
th thousandth digit blinking at 2 Hz . Short press to select
value and short press M to switch to next digit selection. Long press M to confirm input of each digit,
and long press M button again to exit the current setting and return to previous menu. The type of
wheel diameter configuration will be recorded to the controller. If customer chooses wheel diameter
CCF option, then CCF page will be displayed directly when entering the wheel diameter setting.
第22 页/共 27页
Hangzh
ou VeloFox Intelligent Technology Co,. Ltd.
Ver.
1.02
