ADJUSTING DEHUMIDISTAT
Setting during the summer months:
During this period, unless being afflicted with breathing problems, using the
Dehumidistat is unnecessary. Set the slide switch to «OFF». (Do not
exchange in day time; exchange at night time, if cool outside, or if it is not raining.)
Setting during the fall, winter and spring months:
(When severe condensation appears on windows)
1) Determine the humidity level in your house (bring the knob (B)
counterclockwise to its maximum position, then bring it back clockwise
slowly until you hear a «click»).
2) Set the knob to one line under this temperature level or «click».
It is possible (and normal) to experience condensation on your
windows when drastic changes in temperature happen (for example:
-5°C [23°F] to -20°C [-4°F]). In that case, we suggest waiting a few days
to allow the situation to stabilize.
CAUTION
Do not select a temperature below -20°C (-4°F). This could lead to
excessive dryness in the air causing discomfort for the occupants.
2.6 Constructo Main Control
A
DJUSTING AIR SUPPLY CONTROL
1) Select speed «MIN» or «MAX»
using slide switch (A).
• When «MIN» (minimum
speed) is selected, if the knob
(B) is set above the click, the
unit will exchange in low speed
with the outside and if it is set
below the click, the unit will
exchange on high speed with
the outside until the desired
humidity level has been
reached.
• When «MAX» (maximum speed)
is selected, the unit will exchange on high speed with the outside
either if the knob is set below or above the click.
2) To turn off the unit, slide the switch at the «OFF» position.
--5°C
23°F
5
°
C
41
°
F
C
O
M
F
O
R
T
Z
O
N
E
-20°C
-4°F
OFF
MIN MAX
#
X
X
X
X
X
0
1
/
9
8
VC0086
CONSTRUCTO
A
B
2.
Controls (cont’d)
