Ventis™ MX4 Product Manual
© 2014 Industrial Scientific Corporation
42
KEY FOR
V
ENTIS MX4 MONITOR THREE-DIMENSIONAL DIAGR
A
M
Numbe
r
Part Number (P/N) Description
1 17152380-X Ventis MX4 Diffusion Case Top Assembly (includes items 2 and 3)
X = Case Color, where: 0 = Black, 1 = Orange
2 17152429 Sensor Barrier Assembly
3 17145285 Vibrating Motor
4 17150772 Ventis MX4 LCD Assembly
5 17134495 Ventis MX4 Sensor, Combustible Gas (LEL/CH
4
)
6 17134461 Ventis MX4 Sensor, Oxygen (O
2
)
7 17134487 Ventis MX4 Sensor, Carbon Monoxide (CO)
7 17155564 Ventis MX4 Sensor, Carbon Monoxide/Low Hydrogen Interference (CO/H
2
Low)
8 17134479 Ventis MX4 Sensor, Hydrogen Sulfide (H
2
S)
9 17134503 Ventis MX4 Sensor, Nitrogen Dioxide (NO
2
)
10 17143595 Ventis MX4 Sensor, Sulfur Dioxide (SO
2
)
11 17147281 Captive Case Screw, Torx (torque value: 55 oz-in or .39 N.m +/- 10%)
11 17147273 Captive Case Screw, Phillips (torque value: 55 oz-in or .39 N.m +/- 10%)
12 17152506 Suspender Clip Spacer
13 17120528 Suspender Clip
14 17153137 Locking Washer
15 17152507 Screw, Phillips (for use with items 12, 13 and 14)
(torque value: 115 oz-in or .81 N.m +/- 10%)
16 17139262 Screw, Phillips (torque value: 115 oz-in or .81 N.m +/- 10%)
17 17134453-XY Lithium-ion Battery Kit
X = Battery Cover Color, where: 0 = Black, 1 = Orange
(captive screw torque value: 55 oz-in or .39 N.m +/- 10%)
Y=1: UL, CSA, ATEX, IECEx, GOST-R, GOST-K, KOSHA, MED, and SANS approvals
Y=2: MSHA
Y=3: China Ex
Y=4: ANZEx
Y=5: INMETRO
18 17148313-Y Extended Range Lithium-ion Battery Pack
Y=1: UL, CSA, ATEX, IECEx, INMETRO, GOST-R, GOST-K, KOSHA, MED, and SANS approvals
Y=2: MSHA
Y=3: China Ex
Y=4: ANZEx
19 17150608 Alkaline Battery Pack
UL, CSA, ATEX, IECEx, ANZEx, China MA, China KA, and INMETRO approvals (CSA, China MA, and
China KA approved for diffusion monitor only.)
20 17151184-XY Cover, Extended Range Lithium-ion or Alkaline
X = Cover Color, where: 0 = Black, 1 = Orange
(captive screw torque value: 55 oz-in or .39 n.m . +/- 10%)
Y=1: UL, CSA, ATEX, IECEx, GOST-R, GOST-K, and KOSHA approvals
Y=2: MSHA (Extended Range Lithium-ion only)
Y=3: China Ex
Y=4: ANZEx
Y=5: INMETRO
Y=C: China KA
* Item is not user replaceable. The Ventis MX4 monitor must be sent to an authorized ISC Service Center for this item to be replaced.
