TECHNICAL DATA
17 B001686
TECHNICAL DATA
Nominal Voltage 12 V / 24 V
Operating Voltage 8 – 32 V with overvoltage and reverse polarity protection
Current consumption < 175 mA with warning LED
Pulse count range
0.5
-
399 Imp/U (Default: 6Imp/U) programmable via LC
D
or
with optional PC Software.
Sensors
Hall sensor (no open Collector)
Inductive sensor
Blocking oscillator (no open Collector)
Alternator Term. W
Ignition Term. 1
Lightning Coil
LCD size 37 x 11 mm
Protection class IP 67 front side, IP 52 rear side acc. IEC60529
Lens PMMA double lens
Housing Ø85 mm – Polycarbonate (PC), flame retardant acc. UL94-V0
Installation depth 50 mm
Bezels PC (black, white) or ABS (chrome) – several color and shapes
Dial Backlit, different colors (black, white)
Pointer
Backlit, white on black dials; red on white dials
240° deflection angle
Illumination Dial: LED amber (605 nm) Pointer: LED red (632 nm)
Warning LED Red (632 nm)
Operating
temperature
-
2
0°C to +
8
5
°C
with chrome bezel -40°C to +70°C
Storage temperature
-
4
0°C to +80°C
with chrome bezel -40°C to +70°C
Connector Tyco / Hirschmann MQS connector 8/14 pins
Mounting
Spinlock Nut
–
locking height 0.5
–
18
mm
Optional Studs and Brackets – locking height 2 – 13 mm
Certifications CE, Reach, RoHS
