E280 INSTALLATION GUIDE 23
CHAPTER 3
Specifications
This chapter describes the power requirements and dimensions of the e280 and
e280s V2 devices.
Power Rating
• Input power rating: 5V DC, 1A
• Charging via USB-C to computer system or you can use any smartphone or
tablet USB power adapter.
Temperature
• Operating Environment:
• Temperature: 0° to 45° C (23° F to 113° F)
• Relative humidity: 5% to 90% RH non-condensing
• Non-Operating Environment:
• Temperature: -20° to 60° C (-4° F to 140° F)
• Relative humidity: 5% to 93% RH non-condensing
External
Dimensions
Weight
Memory
• 512MB Flash
• 512MB DDR
Magnetic Stripe
Card
• Triple-track
• Supports bi-directional card reader
• Swipe speed at 10 IPS to 40 IPS
Communication
• BT 4.2 BLE (Bluetooth Low Energy)
• Wi-Fi 2.4 GHz (a, b, g ,n, ac), MFI Certified
e280 e280s V2
Length: 121 mm 128.4 mm
Width: 67 mm
Height: 14.15 mm 23 mm
e280 e280s V2
Weight 165 g 225 g
