M400 INSTALLATION GUIDE 11
CHAPTER 2
Setup
This chapter describes the setup procedure for:
• Terminal Location.
• Inside the Shipping Carton.
• Terminal Features.
• Connection Ports.
• M400 Connection Options.
• MSAM Card.
• Terminal Power Source.
• Calibrate Touch Panel.
• Smart Card Reader.
• Magnetic Card Reader.
• Contactless Smart Card Transaction.
• M400 WiFi/BT Support.
• Optional Accessories.
Terminal
Location
The following are guidelines used to select an ideal location for the terminal.
Ease of Use
• Select a location convenient for both merchant and cardholder.
• Select a flat support surface, such as a countertop or table, or mount it on a
mounting stand supplied by Verifone.
• Select a location near a power outlet, POS, ECR, or computer connected to
the terminal. Do not string cables or cords across a walkway for safety.
Environmental
Factors
• Do not use the unit where there is high heat, dust, humidity, moisture, caustic
chemicals or oils.
• Keep the unit away from direct sunlight and anything that radiates heat, such
as a stove or a motor.
• Do not use the terminal outdoors.
