VeriFone M400 - Power and Environmental Specs; Physical and Component Specs

M400 INSTALLATION GUIDE 31
CHAPTER 3
Specifications
This chapter discusses power requirements, dimensions, and other specifications
of the terminal.
Power Rating
• 12 V DC, 1 A
Power Pack
• PWR445-001-01-A
• UL/cUL, ITE listed, LPS power supply
• Input rated: 100-240 V AC, 50/60 Hz
• Output rated: 12 V DC, 1 A, 12 W
Temperature
• Operating temperature: -5° to 50° C (23° to 122° F)
• Storage temperature: -20° to 60° C (-4° to 140° F)
External
Dimensions
• Length: 173 mm (6.81 in.)
• Width: 175 mm (6.89 in.)
• Depth: 43 mm (1.69 in.)
Weight
• Unit weight: 430 g
Processor
• 1 GHz ARM Cortex A9
Memory
• 256 MB of flash memory and 512 MB SDRAM
Display
• 5” IPS LCD
Magnetic Card
Reader
• Triple track (tracks 1, 2, 3), high coercivity, bi-directional
Primary Smart
Card
• ISO 7816, 1.8 V, 3 V, 5 V
• Synchronous and asynchronous cards
