SETUP
M400 Connection Options
20 M400 INSTALLATION GUIDE
USB Interface Module (PN 445-103-01-A)
This module has:
• ICE cube bus in
• ICE cube bus out
• RJ-50 with USB signals
Figure 10 USB Interface Module
Ethernet Interface Module (PN 445-104-01-A)
This module support 10/100 Mbits/sec and has:
• ICE cube bus in
• ICE cube bus out
• RJ-50 with Ethernet signals
Figure 11 Ethernet Interface Module
