TROUBLESHOOTING
5-5
VersaPulse Select Service Manual
0621-499-01 12/95
®
®
DISPLAY, DC POWER SUPPLY AND DISPLAY P/S
FIGURE 5.3 DISPLAY, DISPLAY POWER SUPPLY & LOW VOLTAGE POWER SUPPLY LAYOUTS
AC IN
DC VOLTAGES
OUT
AC IN
DISPLAY
VOLTAGES
FUSE (5A, 250V)
DC POWER SUPPLY
DISPLAY POWER SUPPLY
INTERNAL 4A, 250V LITTLE FUSE
