VXA-300 PILOT III OPERATING MANUAL
35
VOR NAVIGATION
To Select the DVOR Mode
When entering the NAV band (108.000 - 117.975
MHz), the VXA-300 selects the DVOR mode auto-
matically. The “COURSE INDICATOR” field will appear
at the upper left corner on the display, and the “ ”
or “ ” indicator will appear below the “Course
Indicator” field on the display.
Note: The “COURSE INDICA T OR” indicates “ ” when
either your aircraft is too far away from the VOR station
or the frequency is not correctly set to that of the VOR
station. Conversely, the “Course Indicator” will indicate
“ ” when a localizer signal is being received.
The “ ” or “ ” flag indicators tell you whether
the VOR navigation information is based on a course
leading to the VOR station or leading away from the
VOR station.
To change the flag from “ ” to “ ” or vice versa,
press the
[
F
]
key momentarily, then press the
[
3
(
FROM
)]
or
[
2
(
TO
)]
key, respectively.
The small “COURSE INDICATOR” and “ / ” flag
indicators may be toggled to the larger “Frequency”
portion of the display. To do this, press and hold in
the
[ ( )]
key for 2 seconds to toggle to the larger
display area. Press the
[ ( )]
key momentarily
again to return to the smaller displays.
COURSE Indicator
“TO”-“FROM” Flag Indicator
2 seconds
( )
