VX-1210 OPERATING MANUAL 17
Specifications
General
Frequency Range: RX: 0.5 ~ 30 MHz,
TX: 1.6 ~ 30 MHz
Emission Modes: A1A (CW), J3E (LSB/USB), H3E (AM), F1B (AFSK)
Synthesizer Steps: 10 Hz
Antenna Impedance: 50 Ω, Unbalanced
Operating Temperature Range
: –22° F to +140° F (–30° C to +60° C)
Frequency Stability: ±1 ppm
Power Requirements: DC 14.4V Lithium-ion Battery
Current Consumption: Receive (Saver off) 0.5 A, Receive (Saver on) 0.1 A,
Transmit (20 W) 5 A, Transmit (5 W) 3 A
Case Size (WxHxD): 7.6” x 2.9” x 10.8” (193 x 74 x 274 mm)
Weight (approx.): 7.1 lbs( 3.2 kg) with FNB-66LI Lithium-Ion Battery Pack
Transmitter
Power Output: 20 W/5 W (J3E/A1A/F1B),
10 W/2.5 W (H3E) (Selectable)
Modulation Type: Balanced Modulator (SSB: J3E),
Early Stage (Low Level) (AM: H3E)
Spurious Radiation: 56 dB down (Harmonics)
Carrier Suppression: 55 dB
Undesired Sideband Suppression
: 55 dB @ 1.5 kHz tone
Audio Response (A3J): 350 to 2650 Hz (–6 dB)
3rd-order IMD: –31 dB
Microphone Impedance:2 kΩ, condenser
Receiver
Circuit Type: Double Conversion Superheterodyne
Intermediate Frequencies: 47.055 MHz & 10.7 MHz
Sensitivity: 0.25 μV (J3E/A1A, 10 dB S/N)
IF Rejection: 80 dB
Image Rejection: 80 dB
Selectivity (–6 dB/–60 dB): 2.4 kHz/5.0 kHz
Audio Output: At least 1.5 W into 4 Ω @ 10% THD
Clarifier Adjustment Range: ±200 Hz (J3E/A1A/F1B),
±400 Hz (H3E)
Specifications are subject to change without notice or obligation.
