METTLER TOLEDO 2158/2160/2162 Vertex Floor Scales Service Manual
(11/96)
3-2
Frame
(2) Countersunk Holes for
1/2” Flat Head Screws
Typical Each Corner
Fixed Receiver
Figure 3-a: Frame Corner Detail (top view)
1.25”
6.88”
6.25”
1.25”
1.19”
45°
1.19”
6.25”
6.88”
1.88”
(2) 1.06 Dia. Holes
Figure 3-b: Leveling Shim Detail
