Chapter 3: Installation (Top-of-Floor)
Modes of Operation
(11/96)
Modes of Operation
2158 Analog Vertex
The 2158 Vertex uses an analog junction box for summing the load cell
outputs. Only analog compatible indicators will work with the 2158
Vertex. The correct cable connection can be seen in Figure 3-f.
2160 DigiTOL Vertex DLC Mode
WARNING
DO NOT USE THE DigiTOL JUNCTION
BOX IN LOCATIONS CLASSIFIED
HAZARDOUS BY THE NATIONAL
ELECTRICAL CODE (NEC) ARTICLE 500.
The 2160 uses a DigiTOL junction box for summing the load cell
outputs. Only DigiTOL indicators will work with the 2160. In the DLC
mode the indicator acts as the host for the DigiTOL junction box
allowing the scale parameters to be adjusted via the indicator keypad.
Cable connections can be seen in Figure 3-g.
2160 DigiTOL Vertex Smart Mode
When the 2160 is used with the 8505 weight display the junction box
provides the “brains” for operation and become the host for the indicator.
Cable connections can be seen in Figure 3-h.
* For detailed information regarding indicator capabilities and operating
instructions consult the appropriate Mettler Toledo technical manual.
WARNING
DO NOT USE THE DigiTOL JUNCTION
BOX IN LOCATIONS CLASSIFIED
HAZARDOUS BY THE NATIONAL
ELECTRICAL CODE (NEC) ARTICLE 500.
2162 ID Net
The 2162 Vertex uses an ID Net junction box to output an ID Net Data
Format compatible with Mettler Toledo ID1 and ID 5 weight display or
Jaguar Industrial Terminal. Cable connections can be seen in Figure 3-j.
WARNING
DO NOT USE THE DigiTOL JUNCTION
BOX IN LOCATIONS CLASSIFIED
HAZARDOUS BY THE NATIONAL
ELECTRICAL CODE (NEC) ARTICLE 500.
Note: Model 2160 is not compatible
with the model 8510 panel mount
indicator or models 8572 or 8582
counting scales.
