Chapter 12: Reference Material
Reference Drawings
(11/96)
12 Reference Material
Reference Drawings
Scale
General
Dimensions
Quick Pit
Assembly
Fork Lift
Frame
1000 - 5000 lb TC201789 TB201773 TC201787
10000 lb TC201789 TC201774 TC201787
20000 lb TC202033 TC201774 - -
Recommended Spare
Parts
For part number refer to service parts.
Qty. Description
1 Load cell (capacity of cell required is per scale capacity)
1 Junction box circuit board (type of board is per model of scale)
1 Junction box desiccant bag
1 Rocker pin (by capacity of load cell)
2 Rocker pin o-ring (by capacity of load cell)
Load Cell Data
Model number: 745
NTEP certificate of conformance number: 92-108
EC test certificate: T2154 EC Type Approval: T2206
Maximum excitation voltage: 15 VDC or VAC rms
Recommended excitation voltage: 15 VDC
Full scale output: 2 mV/V
Input terminal resistance: 350 Ohm minimum
Output terminal resistance: 350 + 2 Ohms
Temperature range compensation: -10°C to +40°C (+14°F to +104°F)
Safe side load: 100% of full load cell rating
Safe overload: 150% of full load cell rating
