Chapter 11: Service Parts
Load Cell Replacement Procedure
(11/96)
Junction Box
Ref. # Part Number Description Qty.
1 TB100395
TB100515-5
TB100569-4
Analog junction box assembly (model 2158)
Consists of:
*13640300A Analog PCB
TA800218 Desiccant Bag
DigiTOL junction box assembly (model 2160)
Consists of:
*13839900A DigiTOL PCB
TA800218 Desiccant Bag
ID Net junction box assembly ( model 2162)
Consists of:
ME207751 IDNet PCB
ME200308 Lock Nut
ME209911 Washer
TA800218 Desiccant Bag
1
2 MZ0901010379 1/4-20 phillips head screw x 1/4” lg. 4
3 MZ0901010035 3/8 flat head screw x 3/4” lg. 2
4 MZ0901010298 1/2-13 flat head screw x 1 1/2” lg. 8
NS ME504235 Cable, IDNet x 5 m Lg. -
• May have an alpha prefix.
NS = Not Shown
Ramp Option Hardware
5 TA201611 Lug, ramp (per ramp) 2
6 MZ0901030076 3/8 lock washer (per ramp) 2
7 MZ0901010124 3/8-16 hex head bolt x 1” lg. (per ramp) 2
Fork Lift Frame Option Hardware
8 TN201817 Level bubble 1
9 MZ0901010298
MZ0901010451
1/2-13 flat head screw, hex socket x 1 1/2” lg.
1/2-13 flat head screw, hex socket x 1 1/2” lg. S.S.
8
10 TN201631
TN202231
Hold down strap
Hold down strap S. S.
4
11 TN201705 **5/8” spacer plate (UHMW poly) 4
Quick Pit Option Hardware
12 TN202623 Shipping angle 4
13 MZ0901010033 3/8-16 hex head screw x 3/4” lg. 8
14 MZ09011030011 3/8” zinc washer 8
15 MZ0901010249 **1/2-13 flat head screw, hex socket x 2 1/4” lg. 8
16 TN201705 **5/8” spacer plate (UHMW poly) 4
** Parts for 10k capacity ONLY.
To Next Page
