Vertex 2158 - Page 32

METTLER TOLEDO 2158/2160/2162 Vertex Floor Scales Service Manual
(11/96)
7-2
Rough Pit Opening
Rough Pit Opening
Instrument Cable Conduit
Quick-Pit Frame
Quick-Pit Frame
Conduit Entry
Shipping/
Pit Frame Support Bracket
Figure 7-a: Shipping/Pit Frame Support Bracket Detail
Female
Anchor
by
Others
Top of Floor
Quick-Pit Frame
Standard Vertex
Frame
1/2-13 x 1 1/2" LG
Flat Head Socket Screw
Furnished
1 3/4" Dia. Ref.
Figure 7-b: Frame Anchoring Detail
