14
M7 – 11.607
User manual
www.vertidrive.nl
SAFETY SIGNS ON THE SYSTEM
Meaning: High voltage, applies to the control box and electrical connections of
components.
Risk: Electrical hazard.
Location: Control box, electrical components.
Meaning: Magnetic field
Risk: Magnets produce a far-reaching, strong magnetic field. They could damage TV’s
and laptops, computer hard drives, credit and ATM cards, data storage media,
mechanical watches, hearing aids and speakers.
Location: In between the front and back wheels, see figure below.
Meaning: Pinch point.
Risk: Pinching hand or fingers.
Location: Near the wheels.
Meaning: Danger for pacemakers and implanted heart defibrillators
Risk: Magnets could affect the functioning of pacemakers and implanted heart
defibrillators. A pacemaker could switch into test mode and cause illness. A heart
defibrillator may stop working.
Location: Near the magnets.
Meaning: Danger for injection by (U)HP water jet (if applied).
Risk: Force of water is so great that it can penetrate the body. People can be hit not only
by the HP water jet from the nozzle, but also e.q. by water jetting from a suddenly leaking
HP hose or HP connection.
Location: Near the robot and hoses
Location of the magnetism
