User manual
www.vertidrive.nl
FOREWORD
This manual is written to inform you, as a user, how to work safely with our product. The manual provides information
on the level of technical specialist. The system should not be operated by unauthorized personnel or technical
specialist without training.
Read the instructions carefully before installing, start of operation or maintenance. Make sure all security
recommendations and precautions have been read and understood. Also read the security recommendations of
complementary supplier’s documents. The users remain responsible for supervision and compliance with this
manual.
This manual only applies to the “M7 Robot” modular carrier for various applications, and does not describe the
complete “VertiDrive” set of equipment with applicable tools. Upon request different tools for the M7 robot are
available, such as safety winch system and specific designed equipment. Contact the support department of
VertiDrive B.V. for more information.
As a Manufacturer we strongly recommend to:
- Contact VertiDrive B.V. for urgent questions.
- Keep the manual on a dry, safe and available place for everyone who’s involved.
- Keep all security marks on the system visible, replace them if needed.
Equipment supplied by VertiDrive B.V., to which the machine directive is applicable, complies with the CE
declaration of conformity.
LAYOUT OF MANUAL
This manual contains the following subjects:
− Description and operation.
− Testing and fault isolation.
− Disassembly.
− Cleaning.
− Check.
− Repair.
− Assembly.
− Special tools, fixtures, equipment and materials.
REVISION SERVICE
The content of this manual will be updated as required by revisions.
VERIFICATION
All applicable procedures, described in this manual, have been verified by VertiDrive B.V.
The provided images are meant to represent the actual product, but the image content may vary from reality.
