32
M7 – 11.607
User manual
www.vertidrive.nl
MAINTENANCE AND CLEANING
First read the safety instructions in chapter 0. It is important to read all safety measures and to use the personnel
protective equipment accordingly.
The maintenance of all mechanical and electrical parts must be done according to the maintenance instructions of
supplier/sub vendor.
Do not approach the robot if you have a pacemaker or implanted heart defibrillator. Keep 60 cm distance!
The wheels contain powerful magnets. When working on the robot extra caution should be taken to avoid direct
contact between steel tools and the magnets. Use non-ferrous tools! Magnets are very strong and can cause
injuries. The magnets will also affect sensitive electronic and mechanic equipment like cell-phones, watches and
(bank) cards with magnetic strips.
Maintenance must only be performed by authorized and qualified personnel!
Customer is held liable for consequential damage or loss such as damaged products, production downtime, etc. by
failure of the system due to inadequate maintenance or lack of maintenance.
FREQUENCY OF INSPECTION AND MAINTENANCE
In principle the robot only needs very little maintenance beside regular cleaning and replacement of worn tracks.
All other parts only need to be replaced after inspection and judged to see if replacement is needed. It is
recommended to inspect the robot on regular basis. Best inspection can be done by removing the tracks and inspect
all parts.
Maintenance is to be performed on regular base according to Maintenance Inspection Schedule
MAINTENANCE INSTRUCTIONS
VertiDrive keeps a stock of the mechanical parts. See the M7 – 11.607 Parts manual supplied with the robot
When ordering parts specify the part number and describe shortly why a part needs to be replaced.
CLEANING
To insure maximum performance, it is important to keep the robot clean. The inside of the drive assembly should
be kept clean as well (check regularly!). Dirt inside the driving assembly can be removed with (low, max 1 bar)
pressurized air or water. When there is excessive build-up of dirt it will influence the flexible mounting of the
magnets. In this case it is recommended to disassemble the drive unit and clean thoroughly. When reassembling
the individual parts, it is important to ensure all are clean. Nuts and bolts should all be applied with (mounting)
grease.
TROUBLE SHOOTING
When faults occur, it is recommended to contact VertiDrive.
