27
M7 – 11.607
User manual
www.vertidrive.nl
INSTALLATION
GENERAL
Before using the robot, it is mandatory to secure the robot with certified and appropriate fall arrestors. This
equipment is to be supplied by the end user and should be placed by an authorized person to do so.
The commissioning work must only be carried out by authorized personnel. Prior to use of the VertiDrive M7 Robot,
the user/operator must follow operating and safety instructions. Initial training of users/operators is provided by
VertiDrive and or VertiDrive certified representatives/trainers, upon delivery of a new robot.
Customer is responsible for transport of the complete system and therefore he bears all risks of loss, damage or
wear caused during transport.
Environment must meet following requirements
Ambient temperature operating : > +3°C (avoid frost) to +40°C
Commissioning the robot
1. Prior to usage, mark an area with yellow/black ribbon of approx. to ensure a distance from the robot of 6 meters
in all cases. This area should not be entered without the permission of the operator. Always take in account
the possible swing of the robot when the robot falls down.
2. Perform the robot inspection procedure prior connecting it to power (and, if applicable UHP pump). For full
detailed description see M7 – Checklist startup procedure supplied with the robot
3. Connect Robot to the power supply.
It is important to organize the power cable in a way it can’t be tangled or caught between objects. Also caution
should be taken to ensure the power cable is out of reach of the magnetic wheels. It is recommended when
using UHP connections to tie power cable and UHP hose together using proper cable binders.
Unroll the power cable entirely. Connect the cable to the robot and the electric control box. Always use the
securing latch to secure the connectors. Secure the cable on the robot by pushing the attached securing block
over the two guiding pins.
Connect the control box to the main power supply.
4. Keep a minimum of 6 meters from the robot during operation.
5. Test all functions briefly prior to using the robot.
6. Always keep a safe distance from adjacent equipment.
7. Always turn off the power supply when it is necessary to be in close proximity of the robot.
