26
M7 – 11.607
User manual
www.vertidrive.nl
Fall arrestor Pulley
Winch system
Do not place hands or object close to the winches when they are in operation.
Always secure transport frame to a solid object or structure in order to counteract sudden forces on the
winch lines (e.g. if the robot detaches from the surface).
Use appropriate straps to secure the frame to a solid or secure object. As an alternative the frame can be weighted
with 4 sand filled bags to be secured to the lugs at the vertices.
Empty bags will be delivered with the transport frame.
