17
M7 – 11.607
User manual
www.vertidrive.nl
SAFETY PROVISIONS
Emergency shut-off
Dangerous or undesirable situations may arise during usage of the robot. To put an end to such a situation
immediately, a high pressure system has at least two or more emergency shut-offs.
One emergency shut-off is on the high-pressure system, the other one on the remote control and the last
emergency shut-off is controlled from the control box.
Depending on the HP working method, the circumstances and the variant of the cleaning machine or high-
pressure jetting equipment, the emergency shut-offs may be operated by the pump engineer, jetter/operator or
additional emergency stop operator.
The emergency shut-off on the high-pressure system:
• Shuts off the High pressure jetting equipment.
The emergency shut-off on the remote control panel or/and on the control box:
• Stops all movements of the robot;
• The magnetism of the robot will not be influenced.
Wall contact switch
The robot is equipped with a wall contact switch. In case the robot loosens contact with the (steel) surface, the
wall contact switch acts as an emergency shut-off. Refer to chapter “Installation” for how to connect the wall
contact switch to the pump.
VertiDrive strongly recommends to integrate the UHP pump equipment (if applicable) in the emergency circuit inside
the control box.
For machine operator protection whip-checks are used on all UHP hoses to prevent UHP hoses becoming fully
detached from the machine in case the UHP coupling fails.
ENVIRONMENTAL MEASUREMENTS
Noise:
The process causes a noise level that exceeds 80 dB if an UHP pump is applied. Wear hearing protection.
