Liquid injection by UHP water jet
Where
When
Precaution
Warning sign
Near robot, hoses and
UHP pump, if a UHP
pump is applied.
During operation with
UHP near the nozzles,
hoses and pump.
Wear protective clothing.
Crushing hand
Where
When
Precaution
Warning sign
Near the horizontal
rotating axis of the
swingarm.
During operation of the
swingarm.
Do not touch the
swingarm.
Pinching hand
Where
When
Precaution
Warning sign
Near the rotating
wheels.
During maintenance/
adjustment/ cleaning.
Do not touch the rotating
wheels when drives are
powered.
Magnetism
Where
When
Precaution
Warning sign
Between the wheels a
powerful magnet is
present.
During maintenance/
adjustment/ handling.
Use non-ferrous tools.
Between the wheels a
powerful magnet is
present.
Always.
Do not approach the
robot if you have a
pacemaker or implanted
heart defibrillator. Keep
60 cm distance.
Between the wheels a
powerful magnet is
present.
During maintenance/
adjustment/ handling.
Handle robot by the
handle bar during
(un)mounting.
