3. Lower the castor wheels. Avoid entrapment of
hands and/or fingers.
Avoid entrapment of hands and/or fingers!!!
4. The magnetism will directly hold the robot on its
place.
Avoid entrapment of hands and/or fingers!!!
Make sure the swing arm is removed from robot before detaching, otherwise robot will not be able to
detach from the wall!!!
2. Unroll the entire umbilical cable to prevent heat buildup and failure of signals.
3. Connect the male and female connectors on both robot and control box.
4. Connect the strain relieve on the robot and secure this with two locking pins as shown on the picture below.
