MODEL NUMBER GXT4-240VBATT
USED WITH UPS MODEL GXT4-5000RT230; GXT4-6000RT230; GXT4-10000RT230
Dimensions, W x D x H, mm (in.)
Unit (with bezel) 430 x 581 x 173 (16.9 x 22.9 x 6.8)
Shipping 530 x 745 x 475 (20.9 x 29.3 x 18.7)
Weight, kg (lb)
Unit 65 (143.3)
Shipping 80 (176.4); “E” models 76 (167.6)
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Quantity x V 1 x 20 x 12V
Battery Manufacturer, Part # 9AH; CSB UPS12460F2 or CSB HR1234WF2
Backup Time See Table 9.4 below
Environmental
Operating Temp, °C (°F) 0 to 40 (32 to 104)
Storage Temp, °C (°F) -15 to 50 (5 to 122)
Relative Humidity 0-95% non-condensing
Operating Elevation Up to 1000m (3280.83 ft.) at 25°C (77°F)
Agency
Safety IEC62040-1:2008 version
Transportation ISTA Procedure 1E
Table 9.3 External battery cabinet specifications
NUMBER OF
BATTERIES/CABINETS
LOAD PERCENT OF
CAPACITY
230VAC RT MODELS
5KVA 6KVA 10KVA
Internal Battery
10% 95 86 99
20% 42 38 44
30% 36 31 25
40% 29 23 17
50% 24 17 13
60% 18 13 10
70% 14 11 7
80% 12 9 6
90% 11 7 4
100% 9 7 4
Table 9.4 Battery run times, minutes
Vertiv | Liebert GXT4 Installer/User Guide | 59
