Vertiv Liebert GXT3 Series

Questions and Answers

D
Debra LeeAug 14, 2025
Why is the battery indicator illuminated on my Vertiv Liebert GXT3 UPS?
- J
  Jennifer NewmanAug 14, 2025
  The battery indicator illuminates when the Vertiv UPS is operating from battery mode. To resolve this, save your data and close applications. If the utility power is out of tolerance, ensure the utility supply voltage is within acceptable limits for the UPS. Keep the UPS plugged in continuously for at least 24 hours to recharge the batteries. Also, make sure the UPS is securely plugged into the wall receptacle. If the UPS input protection fuse has blown or opened, replace it and then restart the UPS.
K
Kristina GutierrezAug 17, 2025
What to do if Fault and Bypass indicators and all LED segments of battery level indicator are illuminated on my Vertiv Liebert GXT3 UPS?
- A
  Andrea AllenAug 17, 2025
  If the Vertiv UPS is overloaded or the load is faulty, check the load level indicator and remove non-essential loads. Recalculate the load and reduce the number of loads connected to the UPS. Inspect the load for any faults. Make sure the UPS is not overloaded, the ventilation holes are not blocked, and the room's ambient temperature isn't too high. Allow the UPS to cool down for 30 minutes, then restart it. If the UPS still won't restart, it requires service, and you should contact your local dealer, Emerson representative, or Emerson Channel Support.
C
Catherine ShieldsAug 21, 2025
What to do if my Vertiv Liebert GXT3 UPS is overloaded?
- R
  Richard GreenAug 21, 2025
  If your Vertiv UPS is overloaded, it could be that the batteries may not be able to hold a full charge due to age. To address this, check the load level indicator and reduce the load on the UPS. Consider replacing the batteries.
B
Brian PetersAug 23, 2025
What does it mean if the Fault indicator and diagnostic A and C indicators are illuminated on my Vertiv Liebert GXT3?
- M
  Maria MartinezAug 25, 2025
  If the Fault indicator and diagnostic A and C indicators are illuminated on your Vertiv UPS, it means that the UPS has failed the battery test. To resolve this, replace the batteries.
D
David RandolphAug 27, 2025
What does it mean if the Fault indicator and diagnostic A and B indicators are illuminated on my Vertiv Liebert GXT3?
- H
  Heather CarterAug 27, 2025
  If the Fault indicator and diagnostic A and B indicators are illuminated on your Vertiv UPS, it indicates a UPS failure, which could include dual-fan failure, single-fan failure under certain conditions, or battery charger failure. First, make sure the fan is not obstructed. If the fault persists, it requires service.
H
hernandezvirginiaAug 30, 2025
How to fix Vertiv UPS that fails to start when the On/Alarm Silence/Manual Battery Test button is pressed?
- M
  Martin HendersonAug 30, 2025
  If your Vertiv UPS fails to start when you press the On/Alarm Silence/Manual Battery Test button, it could be due to a short circuit or overload. Ensure the UPS is off, disconnect all loads, and check that nothing is lodged in the output receptacles. Also, make sure the loads are not defective or shorted internally.
P
Paul ChavezSep 2, 2025
What to do if the Battery indicator and Bypass indicator are flashing on my Vertiv UPS?
- W
  William RossSep 3, 2025
  If the Battery indicator is flashing and the Bypass indicator is flashing on your Vertiv UPS, it means the battery source is not available, and a continuous horn is sounding. To fix this, check the battery connections, completely power down the UPS, and then restart it.
L
Lori DouglasSep 6, 2025
What does it mean if Fault and Bypass indicators and diagnostic B indicator are illuminated on my Vertiv Liebert GXT3 UPS?
- M
  manningrobertSep 6, 2025
  If the Fault and Bypass indicators and diagnostic B indicator are illuminated on your Vertiv UPS, it indicates a UPS internal DC bus overvoltage. The UPS requires service.
J
John WhiteSep 9, 2025
What does it mean if Fault indicator and diagnostic D indicator are illuminated on my Vertiv UPS?
- O
  odeanSep 9, 2025
  If the Fault indicator and diagnostic D indicator are illuminated on your Vertiv UPS, it indicates a UPS PFC (Power Factor Correction Circuit) fault. The UPS requires service.

Summary

Important Safety Instructions

Battery Safety Precautions

Precautions for handling batteries to prevent electrical shock and short circuit.

General Operational Safety

Precautions for safe operation and maintenance of the UPS unit.

Electromagnetic Compatibility

5 INSTALLATION AND CONFIGURATION

5.1 Install the Main Cabinet

Instructions for installing the primary UPS unit.

5.2 External Battery Cabinet Installation

Procedures for connecting and installing optional external battery cabinets.

5.3 Connect Input;Output Power

Steps for connecting the UPS to input and output power sources.

5.4 IT Power System Configuration-Liebert GXT3-6000 RTL630 Only

6 CONFIGURATION PROGRAM

6.1 Configuration Program Features

Lists key features and capabilities of the UPS configuration program.

8 OPERATION

8.1 Startup Checklist for the Liebert GXT3

8.2 Initial Startup and Electrical Checks

Step-by-step guide for the initial startup and electrical verification of the UPS.

8.3 Manual Battery Test

8.4 Put the Liebert GXT3 in Manual Bypass

8.5 Shut Down the Liebert GXT3

8.6 Disconnecting Input Power from the Liebert GXT3

8.7 Maintenance Bypass

10 MAINTENANCE

10.1 Replacing the Internal Battery Pack

Step-by-step guide for safely replacing the internal battery pack.

10.3 Precautions

10.4 Checking UPS Status

10.5 Checking UPS Functions

10.6 Replacing the Power Module

Instructions for replacing the power module in 8000 and 10,000VA models.

11 TROUBLESHOOTING

11.1 UPS Symptoms

Lists common symptoms indicating a potential UPS malfunction.

11.1.2 Audible Alarm

Explains the audible alarms and their corresponding conditions.

11.2 Troubleshooting

Provides a detailed guide to diagnose and resolve common UPS problems.

Vertiv Liebert GXT3 Series Specifications

General

Type	Online Double Conversion
Frequency	50/60 Hz
Model Series	Liebert GXT3
Output Waveform	Sine Wave
Battery Type	Sealed Lead-Acid (SLA)
Runtime	Varies with load and model
Typical Backup Time	Varies with load and model
Communication Interface	USB, RS-232
Operating Temperature	0°C to 40°C
Humidity	0% to 95% (non-condensing)
Dimensions	Varies with model
Weight	Varies with model
Form Factor	Tower, Rackmount (depending on model)
Input Voltage	120V, 208V, 220V, 230V, 240V (depending on model)
Output Voltage	120V, 208V, 220V, 230V, 240V (depending on model)
