Vertiv Liebert GXT3 Series User Manual

NOTE: Remote Power Off will be performed by NO contact. The current limited source for the optocoupler (+12VDC,
50mA) will be available from UPS. The connection to the Liebert GXT3 for remote connection will be via terminal block
connector. Battery Mode Shutdown wiring must conform to all national, regional and local wiring codes and laws. This
signal must last for 1.5 seconds or longer.
NOTE: A battery shutdown signal will not cause an immediate shutdown. It will start a 2-minute shutdown timer. This
timer cannot be stopped once triggered. If the utility power returns during this countdown, the Liebert GXT3 will still
shut down and must remain shut down for 10 seconds. Whether the UPS turns back On when the power is restored
depends on the auto-restart setting.
9.2.3 On Battery
On Battery signal is a Normally Open (NO) dry contact. When the UPS is supplying output power from the battery this dry
contact will be closed.
9.2.4 Low Battery
Low Battery signal is a Normally Open (NO) dry contact. When the UPS is supplying output power from the battery and has
reached the Low Battery Warning time selected in the configuration program, this dry contact will be closed.
NOTE: The rated values for the dry contacts for the On Battery and Low Battery signals are:
• Rated Voltage: 30V (AC or DC)
• Rated Current: 300mA
9.3 Liebert IntelliSlot
®
Communication Cards
The Liebert IntelliSlot port accepts three optional cards:
• Liebert IntelliSlot SNMP Card
• Liebert IntelliSlot Relay Card
• Liebert IntelliSlot 485 Card.
The Liebert IntelliSlot SNMP Card provides SNMP monitoring and control of the UPS across the network.
The Liebert IntelliSlot Relay Card provides dry contact relay outputs for custom-wired applications and delivers support for
built-in shutdown for AS/400 systems.
The Liebert IntelliSlot 485 Card is used to connect the UPS and computer system.
Follow instructions provided with the Liebert IntelliSlot card to configure Liebert MultiLink
®
, the UPS or any additional
ancillary product for the Liebert GXT3. These instructions are available at
multilink.liebert.com
9.3.1 Liebert MultiLink
®
Liebert MultiLink monitors the UPS continuously and can shut down a computer or server in the event of an extended power
failure.
Liebert MultiLink can also be configured for use without the USB cable when the Liebert IntelliSlot
®
SNMP/Web card is
installed in the UPS. Additionally, Liebert MultiLink can be configured to coordinate shutdown across the network with other
computers running Liebert MultiLink when you purchase a Liebert MultiLink License Kit. For more information about the
Liebert IntelliSlot SNMP/Web Card and Liebert MultiLink License Kits, visit our Web site (www.VertivCo.com) or contact
your local dealer or Emerson representative.
Several option cards are available for use in the Liebert IntelliSlot port of the Liebert GXT3. The Liebert IntelliSlot
SNMP/Web Card provides SNMP and Web-based monitoring and control of the UPS across the network.
The Liebert IntelliSlot MultiPort 4 Card allows installing Liebert MultiLink software on four computers and coordinate
shutdown in the event of a power failure.
The Liebert IntelliSlot Relay Card provides dry contact relay outputs for custom wired applications and delivers support for
built-in shutdown for AS/400 systems.
Vertiv | Liebert® GXT3 ™ Installer/User Guide | 44
