Liebert EXL S1 Technical data
User Manual 10H52226UM60 - Rev. 1 - 01/2017
102
9. TECHNICAL DATA
9.1. Liebert EXL S1 300-500kVA
General conditions of technical data table:
The data shown are typical and refer to 25°C ambient temperature and nominal input and output
conditions, unless otherwise specified. Not all data shown apply simultaneously. Data apply to the
standard version, unless otherwise specified.
For test conditions and measurement tolerances not specified in the table, see the Witness Test
Report procedure.
UPS model Liebert EXL S1
Power (kVA) 300 400 500
System data
AC/AC efficiency in VFI
mode without charging
current, with resistive load
1)
2)
25% load (%)
50% load (%)
75% load (%)
100% load (%)
up to 96
.4
up
to 96.8
up to 96.7
up to 96.3
AC/AC efficiency in Intelligent ECO mode without
charging current, at maximum resistive load
1)
2)
98.7
Heat dissipation at nominal
output load
Float mode VFI (kW)
(Btu/h)
10.4 13.8 17.3
35400 47200 59000
ECO (kW)
(Btu/h)
3.6 4.7 5.9
12140 16180 20230
Noise at 1 m as per ISO 3746
1)
2)
(dBA ± 2dBA)
≤6
5 @ partial load
Noise at 1 m as per ISO 3746
1)
2)
(dBA ± 2dBA)
≤69 ≤71 ≤73
Protection degree with doors open IP20
Mechanical dimensions:
Height (mm) 1950
Width (mm) 1000 1250
Depth (mm) 900
Shipping Weight (kg) 775 1060
Net Weight (kg) 725 990
Number of cabinets 1
Frame color RAL7021
Floor area (depth w/o handle: 830 mm) (m
2
)
0.90 1.13
Floor loading (kg/m
2
)
806 880
Cable entry Bottom
Service access Front and top
Cooling
(m
3
/h)
Forced Ventilation, front air intake, top air outlet
2522 3153
Location Indoor (free from corrosive gases and conductive dust)
Operating temperature (°C) 0-40
Max. relative humidity @ 20°C (non condensing)
(%)
up to 95
