Liebert EXL S1 Technical data
User Manual 10H52226UM60 - Rev. 1 - 01/2017
106
9.2. Liebert EXL S1 600-1200kVA
General conditions of technical data table:
The data shown are typical and refer to 25°C ambient temperature and nominal input and output
conditions, unless otherwise specified. Not all data shown apply simultaneously. Data apply to the
standard version, unless otherwise specified.
For test conditions and measurement tolerances not specified in the table, see the Witness Test
Report procedure.
UPS model Liebert EXL S1
Power (kVA) 600 800 1000 1200
System data
AC/AC efficiency in VFI mode without
charging current, with resistive load
1)
2)
25% load (%)
50% load (%)
75% load (%)
100% load (%)
up to 96.4
up to 96
.6
up
to 96.5
up to 96
.1
AC/AC efficiency in Intelligent ECO mode without charging current, at
maximum resistive load
1)
2)
98.6
Heat dissipation at nominal output load
Float mode VFI (kW)
(Btu/h)
21.9 29.2 36.5 43.8
74780 99700 124600 149500
ECO (kW)
(Btu/h)
7.7 10.2 12.8 15.3
26160 34880 43600 52300
Noise at 1 m as per ISO 3746
1)
2)
(dBA ± 2dBA)
≤70 @
partial load
≤72 @
partial load
Noise at 1 m as per ISO 3746
1)
2)
(dBA ± 2dBA)
≤
76
≤
78
Protection degree with doors open IP20
Mechanical dimensions:
Height (mm) 1950
Width (mm) 2000
2650
3)
Depth (mm) 900
Shipping Weight (kg) 1670
2400
4)
Net Weight (kg) 1550
2155
5)
Number of cabinets 1 2
Frame color RAL7021
Floor area (depth w/o handle: 830 mm) (m
2
)
1.8 2.39
Floor loading (kg/m
2
)
861 954
Cable entry Top/bottom
Service access Front and top
Cooling
Forced Ventilation, front air intake,
top air outlet
(m
3
/h)
4529 6794
Location
Indoor (free from corrosive gases
and conductive dust)
Operating temperature (°C) 0-40
Max. relative humidity @ 20°C (non condensing) (%) up to 95
Max. altitude above sea-level without derating (m)
1000 (for higher altitudes complies
with IEC/EN 62040-3)
Immunity to electrical interference IEC/EN 62040-2:2006
