Vertiv Liebert EXL - External Protection Devices; Differential Protection Devices

Liebert EXL S1 Installation
User Manual 10H52226UM60 - Rev. 1 - 01/2017
43
Figure 22 - Liebert EXL S1 1000/1200kVA - front view
QS1
QS2
QS4
MODULE “A” RECT/INV PHASE U
MODULE “A” BOOST
ST. SW. MODULE
MODULE “A” RECT/INV PHASE V
MODULE “A” RECT/INV PHASE W
MODULE “B” RECT/INV PHASE U
MODULE “B” BOOST
MODULE “B” RECT/INV PHASE V
MODULE “B” RECT/INV PHASE W
