3 INSTALLATION
Do not start the UPS until after the installation is finished.
WARNING! Risk of electrical shock. Can cause equipment damage, injury and death. Before
beginning installation, verify that all external overcurrent protection devices are open (Off), and
that they are locked-out and tagged appropriately to prevent activation during the installation,
verify with a voltmeter that power is Off and wear appropriate, OSHA-approved personal
protective equipment (PPE) per NFPA 70E. Failure to comply can cause serious injury or death.
Before proceeding with installation, read all instructions. Follow all local codes.
3.1 What’s Included
• Terminal Block Communication Terminals
• Compact Disk with:
• Configuration Program
• User Manual (electronic version)
• USB Cable—one, 2m (6-1/2 ft) long
• Rack mounting hardware, including screws,
• Two plastic, tower-stand support-base sets (four pieces)
• Warnings, Safety Instructions booklet and WEEE recycling sheet (ISO 14001 compliance)
NOTE: The GXT4 External Battery Cabinet shipping package includes one battery cabinet, two spacers
for tower configuration and one DC-power cable and rack-mounting hardware, including screws,
handles and mounting rail kit.
3.2 Unpacking and Inspection
Unpack the UPS and conduct the following checks:
• Inspect the UPS for shipping damage. If any shipping damage is found, report it to the carrier
and your local dealer or your Vertiv representative immediately.
• Check the accessories included in packaging list. If there is any discrepancy, contact your local
dealer or your Vertiv representative immediately.
3.3 Preparation for Installation
3.3.1 Installation Environment
• Install the UPS indoors in a controlled environment, where it cannot be accidentally turned Off.
The installation environment should meet the specifications listed in Specifications on page53.
• Place it in an area of unrestricted air-flow around the unit, away from water, flammable liquids,
gases, corrosives, and conductive contaminants. Avoid direct sunlight.
NOTE: Operating the UPS in temperatures above 77°F (25°C) reduces battery life.
3 Installation
21
