Vertiv Liebert GXT4 Series User Manual

NUMBER OF
EXTERNAL
BATTERY
CABINETS
LOAD
PERCENT
OF
CAPACITY
120 VAC RTMODELS
208VAC
RTMODELS
500VA 700VA 1000VA 1500VA 2000VA 3000VA 3000VA
Internal Battery
+ 5 External
Battery Cabinets
10% 2219 2104 1817 1550 1202 1154 1091
20% 1818 1535 1118 836 620 610 587
30% 1433 1093 761 559 412 407 391
40% 1126 827 574 412 301 301 294
50% 909 657 454 324 236 238 233
60% 758 549 373 265 194 197 193
70% 648 465 316 224 165 168 165
80% 571 402 272 194 141 144 142
90% 505 352 238 171 122 126 124
100% 452 313 210 150 108 112 110
Internal Battery
+ 6 External
Battery Cabinets
10% 2321 2223 1979 1740 1421 1369 1302
20% 1980 1740 1344 1008 745 729 698
30% 1653 1317 926 665 495 490 471
40% 1353 1007 690 496 363 362 354
50% 1107 800 550 389 284 286 280
60% 923 659 455 319 232 235 230
70% 789 564 384 268 196 199 196
80% 687 488 331 231 169 173 171
90% 611 429 289 203 147 150 148
100% 547 381 256 180 129 134 132
Run times in this table are approximate. Times are based on new, fully-charged, standard battery modules at a temperature of 77°F
(25°C) with 100% resistive UPS loading. Run times listed above can vary by ±5% due to manufacturing variances of the individual
batteries.
Table 9.5 Battery run times (continued)
9.1 Auto-Learning Battery Run Times
As batteries age, the estimated run times may become less accurate. The Liebert® GXT4 is programmed
to “learn” from a full battery discharge and modify the estimated run time for the measured battery
capacity. This can improve accuracy and compensate for aging batteries or batteries that operate at
different ambient temperatures.
The UPS will update the anticipated run time calculation only under certain conditions.
• The UPS must have a steady load that is greater than 20%.
• The UPS must be at 100% charge at the start of a battery discharge.
Vertiv | Liebert® GXT4™ Installer/User Guide
60
