9 SPECIFICATIONS
MODEL NUMBER GXT4-500RT120 GXT4-700RT120 GXT4-1000RT120
RATING 500VA/450W 700VA/630W 1000VA/900W
Dimensions, D × W × H, in. (mm)
Unit
16.2 x 16.9 x 3.4
(408 x 430 x 85)
Shipping
25.5 x 23.9 x 10.6
(647 x 607 x 270)
Weight, lb (kg)
Unit 40 (18.2)
Shipping 47 (21.4)
Input AC
Voltage Range (typical) 120-VAC nominal; variable based on output load
90% ~ 100% loading 90VAC/140VAC
70% ~ 90% loading 86VAC/140VAC
30% ~ 70% loading 77VAC/140VAC
0 ~ 30% loading 60VAC/140VAC
Frequency 40Hz ~ 70Hz; Auto Sensing
Input Power Cord 10 ft. attached w/ NEMA 5-15P plug
Output AC
Output Receptacles 5-15R × 6
Voltage 110/115/120VAC (user-configurable); ±3%
Waveform Sine wave
Utility (AC) Mode Overload 200% for 2 seconds; 150% for 50 seconds with transfer to bypass
Battery
Type Valve-regulated, non-spillable, lead acid
Qty × V× Rating 4 × 12V × 5.0Ah
Battery Mfr./Part # YUASA/NPH5-12; CSB/ HR 1221W; CSB/GP1245
Backup Time See Battery run times (continued) on page60
Recharge Time
5 Hours to 90% capacity after full discharge with 100% load till UPS auto-shutdown
(Internal Batteries Only)
Environmental Requirements
Operating Temperature, °F (°C) 32 to 104 (0 to 40); see Operating Temperature Parameters on page57
Table 9.1 Specifications for GXT4-500RT120, GXT4-700RT120 and GXT4-1000RT120
9 Specifications
53
