4.5 Prompt List
A prompt screen is displayed during the operation of the system to alert you to certain conditions and/or
to require your confirmation of a command or other operation. See the following table for the prompts and
meanings.
PROMPT MEANINGS
Mains Power Restored The mains power returns and the UPS transfers back to mains (AC) mode.
UPS Return From A Low Battery
Condition
The UPS transfers back to mains (AC) mode from battery low mode.
UPS Return From Battery Mode The UPS transfers back to mains (AC) mode from battery mode.
UPS Self Test Successful The UPS self-test is successfully performed.
UPS Shutdown Command Received The UPS shut down was initiated through communication.
UPS Turn Off The UPS shuts down and has no output power.
UPS Turn On The UPS starts up successfully and supplies protected power to the load.
UPS Shutdown Process Had Been
Canceled
The shutdown command sent through SNMP card to the UPS is canceled,
ECO Mode Enabled The UPS is configured to ECO mode operation,
ECO Mode Disabled
The UPS is configured to Online mode, supplying protected power to the load through
the inverter.
UPS Internal Temperature Return To
Normal
The internal temperature of the UPS recovers to normal range.
UPS Load Return From Overload The loads are reduced, and the UPS recovers to normal state from overload.
Load On Inverter The inverter is on and supplies protected power to the load.
Load On ECO Bypass
The UPS is on ECO mode; the mains is supplying power to the load directly to reduce
energy usage.
OUTLET1 Closed Auto / Manual The programmable output receptacle 1 received a turn-off command and is turned Off.
OUTLET1 Open Auto / Manual The programmable output receptacle 1 received a Turn-On command and is turned On
OUTLET2 Closed Auto / Manual The programmable output receptacle 2 received a Turn-Off command and is turned Off.
OUTLET2 Open Auto / Manual The programmable output receptacle 2 received a turn-on command and is turned On.
Bypass Power Restored The bypass power recovered and the UPS can now transfer to bypass.
Table 4.3 System prompts and meanings
