Premium Efficiency Control Board Configuration Notes
• J6 is the CANbus termination jumpers. If the condenser is the last device in the CANbus
communication line, the jumper must be placed between Pins 1 and 2 of J6. If the condenser is
not the last device in the CANbus communication line, then the jumper on J6 must be placed
on Pins2 and 3. CANbus communication errors may occur if the jumpers are not in the correct
positions.
• A jumper must be present at J2. If a jumper is not present, the control board will not boot
properly during power startup.
Sub-
menu
ID
Meaning
Default R407c Default R410a
Default R407C
W/LT
Default R410a
W/LT
Comments
Metric Imperial Metric Imperial Metric Imperial Metric Imperial
C00 EBM address 1 1 1 1
Do not change
unless properly
instructed.
C01
ZIEHL_ABEGG
address
1 1 1 1
C02
FANS_TECH
address
1 1 1 1
C03 EC Fan 1 model ID 0 0 0 0
C04 EC Fan 2 model ID 0 0 0 0
C05 EC Fan 3 model ID 0 0 0 0
C06 EC Fan 4 model ID 0 0 0 0
C07 System model ID 0 0 0 0
"0" = Single, "1" =
Dual
C09
System
refrigerant type
2 3 2 3
"2" = R407c, "3" =
R410a
C10
Condenser
pressure absolute
max 1
18.0 bar 261 psi 28.0 bar 406 psi 18.0 bar 261 psi 28.0 bar 406 psi
R407c - 17-25 bar;
247-362 psi
C11
Condenser
pressure absolute
max 2
18.0 bar 261 psi 28.0 bar 406 psi 18.0 bar 261 psi 28.0 bar 406 psi
R410a - 25-38 bar;
363-550 psi
C12
Condenser
pressure absolute
min 1
12.0 bar 174 psi 18.0 bar 261 psi 14.0 bar 203 psi 20.0 bar 290 psi
R407c - 11-17 bar;
160-246 psi
C13
Condenser
pressure absolute
min 2
12.0 bar 174 psi 18.0 bar 261 psi 14.0 bar 203 psi 20.0 bar 290 psi
R410a - 16-24 bar;
232-347 psi
C14
Condenser
pressure PID Kp
1.00 1.00 1.00 1.00
Do not change
unless properly
instructed.
C15
Condenser
pressure PID Kip
0.02 0.02 0.02 0.02
C16
Condenser
pressure PID Kdp
0.00 0.00 0.00 0.00
C17
Refrigerant
temperature max
1
35°C 95.0°F 35°C 95.0°F 35°C 95.0°F 35°C 95.0°F
Range 30 - 40°C;
86 - 104°F
C18
Refrigerant
temperature max
2
35°C 95.0°F 35°C 95.0°F 35°C 95.0°F 35°C 95.0°F
Table 11.2 Premium Efficiency Control Board Configuration-parameter List
