3.1 Equipment Inspection
Upon arrival of the unit and before unpacking, verify that the labeled equipment matches the Bill of
Lading. Carefully inspect all items for either visible or concealed damage. Damage should be immediately
reported to the carrier and a damage claim filed with a copy sent to Vertiv™ or to your sales
representative.
If you have the seismic mounting kit, refer to Liebert Seismic Application—OptionalUnitConfiguration on
page99
3.1.1 Packing Material
All material used to package this unit is recyclable. Please save it for future use or dispose
of the material appropriately.
Figure 3.1 Equipment recommended for handling a Liebert condenser
3.2 Handling Unit on the Skid
Transport unit using a fork lift or a crane with sling and spreader bars.
Using a forklift
NOTICE
Risk of improper forklift handling. Can cause unit damage.
Keep the forklift tines level and at a height that will fit under the skid.
• Make sure the forks (if adjustable) are spread to the widest allowable distance to still fit under
the skid.
• Type of forklift used will depend on the terrain the unit is to be moved across during handling.
• Minimum forklift fork length:
• for 1-fan and 2-fan units—48” (1219mm)
• for 3-fan and 4-fan units—72” (1829mm)
• When moving the packaged unit, do not lift it any higher than 6" (152mm). If the unit must be
lifted higher than 6" (152mm), great care must be exercised and no one may be closer than 20'
(6m) to the lift point.
• Vertiv™ recommends lifting one end off the ground no more than 6" (152mm)and using the
forklift to push or pull the unit.
