Model #
Number of
Fans
Domestic Packaging Export Packaging
Weight lb (kg)
Dimensions
(L x W x H) in.
(cm)
Volume ft
3
(m
3
)
Weight lb (kg)
Dimensions
(L x W x H) in.
(cm)
Volume ft
3
(m
3
)
MCL165 3
1364
(619)
196 x 36 x 63
(498 x 91 x 160)
257 (7.3) 1619 (734)
197 x 37 x 64
(500 x 94 x
163)
270 (7.7)
MCL220 4
1835
(832)
256 x 36 x 63
(650 x 91 x 160)
336 (9.5) 2160 (980)
257 x 37 x 64
(653 x 94 x 163)
352 (10)
1. Packaged weights will increase with factory options, such as legs taller than 18" (457mm), coated coils, 575V and seismic/wind
options. See Table 2.2 below, Table 2.3 below and Table 2.4 on the facing page for option weights to add to the packaged weights
above. Consult factory for additional information.
2. Receivers and 60" legs are shipped separately from the condenser.
Table 2.1 Condenser shipping weights, dimensions and volume, approximate (continued)
2.2.1 Condenser and Options Net Weights
Total unit weight is the sum of the condenser weight with the selected legs plus the weight of any option.
Source: DPN003034, Rev. 1
Condenser Model MCS028 MCS056
Refrigeration Circuits 1 2
Condenser Dry
Weight, lb (kg)
18" Leg
154 (70) 270 (122)
36" Leg
286 (130) 419 (190)
48" Leg
318 (144) 451 (205)
60" Leg
349 (158) 482 (219)
Additional Weight for Options, lb (kg)
Liebert Lee-Temp 55 (25) 110 (50)
Coated Coil 4 (2) 8 (4)
575V 52 (24) 63 (29)
Seismic/Wind Bracing, 18-in. legs 40 (18) 40 (18)
Table 2.2 Condenser and option net weights—Small condensers
Condenser Model MCM040 MCM080 MCM160
Refrigeration Circuits 1 1 2 2
Condenser Dry
Weight, lb (kg)
18" Leg
231 (105) 441 (200) 441 (200) 860 (390)
36" Leg
363 (165) 590 (268) 590 (268) 1066 (484)
48" Leg
395 (179) 622 (282) 622 (282) 1114 (505)
60" Leg
426 (193) 653 (296) 653 (296) 1160 (526)
Table 2.3 Condenser and option net weights—Medium condensers
Vertiv | Liebert® MC™ Installer/User Guide | 16
