Model # Number of Fans Condenser Circuits
Connection Sizes, OD, in
Hot Gas Line Liquid Line
MCM160 4 2 1-1/8 7/8
MCL220 4 2 1-3/8 1-1/8
Source: DPN002425, Rev. 5
Table 5.3 Piping: dimensions—Dual-circuit, two-fan and four-fan units (continued)
Figure 5.10 Piping: Dimensions with Liebert Lee-Temp
™
—Dual circuit condensers
