32 5 Specications
Vertiv™ | Liebert® PSI5 120 V Input / 120 V Output & 208 V lnput / 208 V Output Installer/User Guide
MODEL PSI5-800RT120 PSI5-1100RT120
PSI5-1500RT120
/ PSI5-1500RT-
120TAA
PSI5-2200RT120
/ PSI5-2200RT-
120TAA
PSI5-3000RT120
/ PSI5-3000RT-
120TAA
PSI5-5000RT120
High Line Normal to
Buck
110 / 121 / 127 / 132 / 138 VAC
220 / 229 / 242 /
253 / 264 VAC
High Line Buck to
Normal
107 / 118 / 123 / 128 / 134 VAC
214 / 223 / 235 /
246 / 257 VA
Low Line Boost to
Normal
93 / 102 / 107 / 112 / 116 VAC
186 / 193 / 205 /
214 / 223 VAC
Low Line Normal to
Boost
90 / 99 / 104 / 108 / 113 VAC
180 / 187 / 198 /
207 / 216 VAC
Low Line Battery to
Boost
80 / 88 / 92 / 96 / 100 VAC
160 / 166 / 176 /
184 / 192 VAC
Low Line Boost to
Battery
75 / 83 / 86 / 90 / 94 VAC
150 / 156 / 165 /
173 / 180 VAC
Frequency Input
Range
55 to 65 Hz (57 to 63 Hz Battery to Normal comeback)
Internal Rear Panel
lnput Breaker
10 A 13 A 16 A 20 A 30 A
Input Surge
Protection
ANSI C62.41 Category A, Level 3
1372J
EN6100-4-5,
Level 3
2064J
Input Power Cord NEMA 5-15P, oset 90-degree type (3 m attached)
NEMA L5-20P
(3 m attached)
NEMA L5-20 to
5-20P adapter
cord (150 mm)
NEMA L5-30P
(3 m attached)
NEMA L6-30P
(3 m attached)
Output
Output Voltages
(on battery)
100 / 110/ 115 / 120 / 125 VAC (±1.5 on battery before alarm) user selectable
(120 VAC is factory default)
200 / 208 /
240VAC (±1.5 on
battery before
alarm) user
selectable
(208 VAC is
factory default)
Output Frequency
(on battery)
60 (default)/ 50 Hz ±1%
Output Receptacles
- not controllable
(3) NEMA 5-15R
(3) NEMA
5-15/20R,
(1) NEMA
L5-20R
(3) NEMA
5-15/20R,
(1) NEMA
L5-30R
(3) NEMA L6-30R
Output Receptacles
- controllable
(3) NEMA 5-15R (3) NEMA 5-20R (1) NEMA L6-30R
Transfer Time
Adjustable with User Setting
09 ST1: 4-6 ms typical, 10 ms max. (default).
ST2: 6-8 ms typical, 11 ms max.
ST3: 8-10 ms typical, 13 ms max.
Output Waveform
(on battery)
Pure Sinewave
Output Overload
Operation
100% — Alarm warning
110% — Alarm warning and shutdown after 10 seconds
120% — Alarm warning and immediate shutdown
Protection Electronic (overcurrent, short circuit w/ latching shutdown)
AC Mode Eiciency 96% for 100 / 110 / 115 / 120 / 125 VAC
Buck and Boost
Mode Eiciency
93% for 100 / 110 / 115 / 120/ 125 VAC
Recharge Time 6-8 hours to recover to 90%
