71 PSI5 Description
Vertiv™ | Liebert® PSI5 120 V Input / 120 V Output & 208 V lnput / 208 V Output Installer/User Guide
1.3 Front Panel
NOTE: For detailed descriptions of the LCD, see Display Panel Indicators on page 19.
Figure 1-7 Controls and Display on 2U and MT Models
ITEM DESCRIPTION
1 ON/MUTE button. See Controls on page 18, for details.
2 SELECT button. See Controls on page 18, for details.
3 OFF/ENTER button. See Controls on page 18, for details.
Figure 1-8 Controls and Display on 1U Models
ITEM DESCRIPTION
1 ON/MUTE button. See Controls on page 18, for details.
2 SELECT button. See Controls on page 18, for details.
3 OFF/ENTER button. See Controls on page 18, for details.
