Figure 3.7 Removing the Covers
Item Description
1 M8x12 low profile
2 Skin to be removed
Figure 3.8 Installing the Plinth End
Item Description
1 M8x16 socket head to mount plinth end to frame
2 Plinth end to install
3 Packaging and Handling Proprietary and Confidential ©2024 Vertiv Group Corp. 19
Vertiv™ UL891 Switchboard Installer/User Guide
