Vertiv I VRC Self-Contained System I User Manual
1.5 Technical Specifications
The detailed technical specifications which include the mechanical and the electrical details are mentioned
in the below table:
Table 1-1 Technical specifications
Parameters
Specification
Model
VRC100
VRC101
VRC102
Certification
UL484
UL484
CE
(EN 60335-1; EN 60335-2-40;
EN 55014-1; EN 55014-2; EN 61000-3-2;
EN 61000-3-3; EN 50581)
Cooling Capacity, kW
0.9 - 3.6
0.9 - 3.6
0.9 - 3.6
Air Volume, m3/h (CFM)
750 (441)
750 (441)
750 (441)
Max Power Input, kW
1.63
1.86
1.86
Full Load Amperage, A
16.5
13
11.5
Dimensions (Without
Package)
W x D x H mm (Inches)
442x978x439 (17.4” x 38.5” x 17.28”)
Input Type
Power Cord (3.2m)
with NEMA 5-20P
Power Cord (3.2m)
with NEMA L6-20P
IEC 60320 C20 Inlet
+ Interconnection Cable (3.0m)
IEC 60320 C19 to C20
Voltage (Vac)
L+N+G, 120 Vac
L1+L2+G, 208
Vac/230 Vac
L+N+PE, 230 Vac
Frequency, Hz
60
50/60
Color
EG7021 (Black)
System Protection Grade
IP20 (IEC 60529)
Net Weight, kg (lbs)
72 (158.7)
74 (163.1)
Gross Weight, kg (lbs)
134 (295.4)
Noise Level, dB(A)
<66
In the case that VRC is installed on the bottom of the rack, the maximum capacities at various evaporator
and condenser air inlet temperatures are mentioned below:
Maximum Capacity, kW
Condenser Air Temperature
29.4 °C (85 °F)
35 °C (95 °F)
40 °C (104 °F)
Evaporator Air Temperature to
Cooling Module
(Return Control)
29.4 °C (85 °F)
3.1
2.6
2.2
35 °C (95 °F)
3.4
3.3
2.8
40 °C (104 °F)
3.6
3.5
3.1
Maximum Capacity, kW
Condenser Air Temperature
25 °C (77 °F)
30 °C (86 °F)
35 °C (95 °F)
Evaporator Air Temperature to
IT Devices
(Supply Control)
19 °C (66 °F)
3.3
3.2
3.1
21 °C (70 °F)
3.5
3.4
3.3
23 °C (73 °F)
3.6
3.5
3.4
