Vertiv I VRC Self-Contained System I User Manual
Appendix I: System Diagram
Condenser
Electronic Expansion
Valve
Distributor
Evaporator
Service
Valve
Service
Valve
High
Pressure
Transducer
Discharge
Temperature
Sensor
High Pressure
Switch
Suction Temperature
Sensor
Suction Pressure
Transducer
Compressor
