If a hand pallet truck or an electric forklift truck is used, the tines of the hand pallet or electric forklift must
be aligned with the center of gravity to prevent the package from toppling or falling over as depicted in
Figure 2-3.
Figure 2-3 Forklift direction
While moving the package, the obliquity has to be maintained at an angle of 90 ± 10 °. Figure 2-4 depicts
the 90 ± 10 ° obliquity that is suitable to move the unit to the vicinity of the desired location.
Figure 2-4 Carrying obliquity
NOTES:
• Ensure that the equipment stands upright. Do not place the equipment outdoors.
• While using the forklift or the hand pallet truck, ensure that the fork arms (if adjustable and
flexible) open to the greatest extent. This is done so that the fork arms can be placed under the
pallet of the equipment in a precise manner.
• Ensure that the length of the fork arms match with that of the equipment.
