The accessory list is shown in the table below.
Table2-4 Accessory list
Sr No.
Item
Quantity
1
Transition Part
1
2
Flex Duct (3.8 m / 12.5 ft.)
1
3
Duct Clamp
2
4
Ceiling Tile Kit
Ceiling Tile for Air Outtake
1
Ceiling Tile for Filter Pad
1
5
Drainage Kit
Condensate Pump Kit
1
Condensate Pump Brackets
1
Condensate Water Pipe (7.5 m / 24.6 ft.)
1
6
L-shape Mounting Rail Kit
2
7
SIC Card Kit
1
8
Pan-Head Screws M6x12 (Torx T30)
20
9
Cage Nuts (M6)
20
10
Pan-Head Screws M5x12 (Torx T25)
10
11
Contact Washers for Pan-Head Screw M5x12
10
12
Center Screws M5x12 (Torx T20)
10
13
Display kit
Display
1
10 m (32.8 ft.) Cable of Display
1
0.5 m (1.6 ft.) Cable of Display
1
14
Evaporator Filter
1
15
User Manual
1
16
Cable Ties 100x2.5
5
17
USB Converter Cable
1
18
Lifting Straps
2
19
VRC Cooling Unit
1
20
VRC102 Power Cable (Only for VRC102)
1
Following the steps below during the unpacking process. For installation, please refer to chapter 3.
• Move the equipment to level ground.
• Unlock the wooden case from the wooden pallet.
• Pull up the wooden case.
• Put the EPE and the ceiling tile kit aside.
• Remove the VRC 10X unit from the wooden pallet that is beneath the VRC 10X unit.
