LaserPLUS Installation Manual VESDA
®
2 Version 1.5
1. Introduction
Scope of this Manual
This manual is intended for installation technicians to be able to install, perform basic
power and preliminary device checks for the LaserPLUS detector. It does not cover
information for commissioning. All VESDA equipment is to be commissioned by
personnel who have attended a VESDA accreditation course.
Use the checklist in Section 9 to verify that the installation has been correctly completed.
Fill out the details in the checklist sheet for the site and submit it to the appropriate
personnel.
CAUTION
• The Detector must only be installed by VESDA accredited personnel.
• The performance of the system depends on the pipe network designed for the
site. Any alteration to the pipe network may alter the performance of the system.
The ASPIRE™ design tool is to be used to verify the suitability of any pipe
network design and subsequent alterations. ASPIRE™ is available from your
distributor or local Vision office
.
• The IP rating for the LaserPLUS is IP 30. This rating indicates the device is not
to be installed where there is the possibility of any water or liquid falling onto
the device.
WARNING
• It is strongly recommended that the mounting bracket be used during
installation.
• The chassis assembly and Central Processor Card should NOT TO BE
REMOVED or disassembled during installation. Follow the installation
procedure outlined in this manual.
