Vespa LX 50 User Manual

03_13
CAUTION
THE BRAKING CIRCUIT FLUID IS HIGHLY CORROSIVE. THEREFORE, WHEN
TOPPING IT UP, AVOID LETTING IT COME INTO CONTACT WITH THE PAINTED
PARTS OF THE VEHICLE. THE BRAKING CIRCUIT FLUID IS HYGROSCOPIC,
THAT IS, IT ABSORBS HUMIDITY FROM THE SURROUNDING AIR. IF MOISTURE
CONTAINED IN THE BRAKE FLUID EXCEEDS A CERTAIN VALUE, THIS WILL
RESULT IN INEFFICIENT BRAKING.
03_14
Battery (03_14)
To access the battery, tilt the saddle forwards, then remove the battery compartment
access door by unscrewing the star-shaped screw "A" shown in the figure.
The battery is the electrical device that requires the most frequent attention and the
most thorough maintenance.
WARNING
USED BATTERIES ARE HARMFUL FOR THE ENVIRONMENT. COLLECTION
AND DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH REGULA-
TIONS IN FORCE.
34
3 Maintenance

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
