Electric characteristic
Bulbs
1 12V35/35W bulb for high- and low-beam light
1 12V-5W bulb for side light
03_18
03_19
Headlight adjustment (03_18, 03_19)
Proceed as follows:
1. Place the vehicle in running order and with the tyres inflated to the prescribed pres-
sure, on a flat surface 10 m away from a white screen situated in a shaded area,
making sure that the longitudinal axis of the vehicle is perpendicular to the screen;
2. Turn on the headlight and check that the borderline of the projected light beam on
the screen is no higher than 9/10 or lower than 7/10 of the distance from the ground
to the centre of the vehicle's headlamp;
3. If otherwise, adjust the right headlight with screw «A».
N.B.
THE ABOVE PROCEDURE COMPLIES WITH THE EUROPEAN STANDARDS RE-
GARDING MAXIMUM AND MINIMUM HEIGHT OF LIGHT BEAMS. REFER TO THE
STATUTORY REGULATIONS IN FORCE IN EVERY COUNTRY WHERE THE VE-
HICLE IS USED.
40
3 Maintenance

Other manuals for Vespa LX 50

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vespa LX 50 and is the answer not in the manual?

Vespa LX 50 Specifications

General IconGeneral
Engine TypeSingle-cylinder, 4-stroke
Displacement49.9 cc
Fuel SystemCarburetor
Front Brake200 mm disc
Rear Brake110 mm drum
Seat Height785 mm
Fuel Tank Capacity8.6 liters
Tires Front110/70 - 11"
Tires Rear120/70 - 10"
Length1, 770 mm
Width705 mm
Cooling SystemAir cooled
TransmissionAutomatic
Max Power3.2 kW
Max Torque4.2 Nm
